| USB |
|---|
| 支持 USB3.0，兼容 USB2.0 |
| USB 视频符合 UVC1.0 协议 |
| USB 音频符合 UAC1.0 协议 |
| USB 视频输出支持 YUV422 和 MJPEG 两种模式 |
| USB 视频输出分辨率：默认最大分辨率 1920×1080P@60Hz |
| USB 3.0 视频输出支持的分辨率 | |
|---|---|
| YUV422 | MJPEG |
| 1920×1080@60Hz/50Hz/30Hz/20Hz/10Hz | 1920×1080@60HZ/50Hz/30Hz/20Hz/10Hz |
| 1600×1200@60Hz/50Hz/30Hz/20Hz/10Hz | 1600×1200@60Hz/50Hz/30Hz/20Hz/10Hz |
| 1360×768@60Hz/50Hz/30Hz/20Hz/10Hz | 1360×768@60Hz/50Hz/30Hz/20Hz/10Hz |
| 1280×1024@60Hz/50Hz/30Hz/20Hz/10Hz | 1280×1024@60Hz/50Hz/30Hz/20Hz/10Hz |
| 1280×960@60Hz/50Hz/30Hz/20Hz/10Hz | 1280×960@60Hz/50Hz/30Hz/20Hz/10Hz |
| 1280×720@60Hz/50Hz/30Hz/20Hz/10Hz | 1280×720@60Hz/50Hz/30Hz/20Hz/10Hz |
| 1024×768@60Hz/50Hz/30Hz/20Hz/10Hz | 1024×768@60Hz/50Hz/30Hz/20Hz/10Hz |
| 800×600@60Hz/50Hz/30Hz/20Hz/10Hz | 800×600@60Hz/50Hz/30Hz/20Hz/10Hz |
| 720×576@60Hz/50Hz/30Hz/20Hz/10Hz | 720×576@60Hz/50Hz/30Hz/20Hz/10Hz |
| 720×480@60Hz/50Hz/30Hz/20Hz/10Hz | 720×480@60Hz/50Hz/30Hz/20Hz/10Hz |
| 640×480@60Hz/50Hz/30Hz/20Hz/10Hz | 640×480@60Hz/50Hz/30Hz/20Hz/10Hz |
| USB 2.0 视频输出支持的分辨率 | |
|---|---|
| YUV422 | MJPEG |
| 1920×1080@10Hz/5Hz | 1920×1080@50Hz/30Hz/25Hz/20Hz/10Hz |
| 1600×1200@10Hz/5Hz | 1600×1200@60Hz/50Hz/30Hz/20Hz/10Hz |
| 1360×768@15Hz/8Hz | 1360×768@60Hz/50Hz/30Hz/20Hz/10Hz |
| 1280×1024@15Hz/8Hz | 1280×1024@60Hz/50Hz/30Hz/20Hz/10Hz |
| 1280×960@15Hz/8Hz | 1280×960@60Hz/50Hz/30Hz/20Hz/10Hz |
| 1280×720@20Hz/10Hz | 1280×720@60Hz/50Hz/30Hz/20Hz/10Hz |
| 1024×768@20Hz/10Hz | 1024×768@60Hz/50Hz/30Hz/20Hz/10Hz |
| 800×600@30Hz/20Hz/10Hz | 800×600@60Hz/50Hz/30Hz/20Hz/10Hz |
| 720×576@60Hz/25Hz/20Hz/10Hz | 720×576@60Hz/50Hz/30Hz/20Hz/10Hz |
| 720×480@60Hz/30Hz/20Hz/10Hz | 720×480@60Hz/50Hz/30Hz/20Hz/10Hz |
| 640×480@60Hz/30Hz/20Hz/10Hz | 640×480@60Hz/50Hz/30Hz/20Hz/10Hz |
|
